UncategorizedRadial Drill Machine 40 MM CAP
| Drill capacity |
40 mm |
| Pillar diameter |
165 mm |
| Spindle nose to table distance |
705 mm |
| Distance from spindle to Center to Pillar Face |
930 mm Maximum , 490 MM Minimum |
| Distance from spindle Nose to base |
850 mm/th> |
| Spindle Nose |
M.T. 4 |
| Number of Spindle speed |
8 speed |
| Range of speed (R.P.M) |
70 to 2000 |
| Work table size (in mm) |
305 x 290 x 290 |
| Base size (machined area) |
930 x 730 MM |
| Overall base size |
1270 x 730 MM |
| Spindle travel |
255 mm |
| WIGHT OF MACHINE |
850 KG WITHOUT MOTOR |
| Pillar height (Regular) |
1450mm |
| Weight (Approx) |
850 Kg Without Motor |
| Work Table Size (In MM) |
380 x 290 x 290 |
| V-belt spindle |
B-47 |
| V-belt lifting |
A-25 |
| No. of T Slots |
4 |
| Type of Feed |
FINE FEED |
| Extra Long Pillar Height |
1830 MM |
| Overall Dimension |
2020L X 330D X 780W |
| Motor Capacity Elevator Motor |
0.5 HP, 1440 RPM |
| Spindle Motor |
1.5 HP, 1440 RPM |
| 2 coolant tank in base plate |
